Solid Micro Grain Carbide
Spiral Flute Router Bits
For Wood, Wood Composite, Plastic, and Aluminum
Our router bits are manufactured in Canada
with the latest in CNC technology. We manufacture
precision
ground tools to your specifications, using only the best micro
grain carbide available.
0
Flute Up Shear
Application:
Plastic, Aluminum, Wood, and Wood
Composite
Part #
Diameter
Cutting Length
Overall Length
A125-1F-R
1/8"
1/4"
1-1/2"
A187-1F-R
3/16"
1/2"
2"
A187-1F-L
3/16"
3/4"
2-1/2"
A250-1F-R
1/4"
3/4"
2-1/2"
A250-1F-L
1/4"
1-3/8"
2-1/2"
A375-1F-L
3/8"
1-3/8"
3"
A500-1F-L
1/2"
1-3/4"
4"
0
Flute Down Shear
Application:
Plastic, Aluminum, Wood, and Wood
Composite
Part #
Diameter
Cutting Length
Overall Length
J125-1F-R
1/8"
1/4"
2"
J187-1F-R
3/16"
1/2"
2"
J187-1F-L
3/16"
3/4"
2-1/2"
J250-1F-R
1/4"
3/4"
2-1/2"
J250-1F-L
1/4"
1-3/8"
2-1/2"
J375-1F-L
3/8"
1-3/8"
3"
J500-1F-L
1/2"
1-3/4"
4"
0
Flute Up Shear – Radius Corner
Maximizes chip flow and finish
Runs very quiet
Sharper angles
3D Carving, Routering & Sculpting
Application:
3D Carving, Sculpting & Routering
Part #
Diameter
Cutting Length
Overall Length
A125-1F-R-RAD
1/8"
1/4"
2"
A187-1F-R-RAD
3/16"
1/2"
2"
A187-1F-L-RAD
3/16"
3/4"
2-1/2"
A250-1F-R-RAD
1/4"
3/4"
2-1/2"
A250-1F-L-RAD
1/4"
1-3/8"
2-1/2"
A375-1F-L-RAD
3/8"
1-3/8"
3"
A500-1F-L-RAD
1/2"
1-3/4"
4"
Back to
Top
Slotting and grooving with upward chip removal
Best finish on bottom side
Rapid cuts as chips are cleared away
Best for harder material
Smoother cutting action with stability through
cut
2
Flute Up Shear
Application: Wood
and wood composite
Chipbreakers are staggered
on the flutes, breaking the chip into small pieces
to give a smooth finish.
Add Chipbreakers to 1/2" & larger
TiAlN coating will increase
the tool life on most materials and increase cutting
time with most applications.
Part #
Diameter
Cutting Length
Overall Length
E12522MR3
1/8"
1/2"
2"
E18722MR3
3/16"
3/4"
2- 1/2 "
E18722ML3
3/16"
1"
2-1/2"
E25022MR3
1/4"
7/8"
2-1/2"
E37522MR3
3/8"
1"
3"
E37522ML3
3/8"
1-1/4"
3"
E50022MR3
1/2"
1-1/4"
3"
E50022ML3
1/2"
1-3/4"
4"
3
Flute Up Shear
3 Flute will increase tool life
They are more ridgid with less
cut interuption than a 2 flute
Better finish and dimension accuracy
Performance will depend on accuracy
of spindle
Application:
Recommended for abrasive or dense materials, when
fine edge quality is required
Part #
Diameter
Cutting Length
Overall Length
E50032ML3C
1/2"
2"
4"
Back to
Top
2
Flute Down Shear
Application: Wood
and wood composite
Available with Chipbreakers & TiN Coating
Better for hold down with downward
chip flow
Best finish on top side of material
Reduced cutting speed, as chips
are pushed back into material
Part #
Diameter
Cutting Length
Overall Length
J12522MR3
1/8"
1/2"
2"
J18722MR3
3/16"
3/4"
2-1/2"
J18722ML3
3/16"
1"
2-1/2"
J25022MR3
1/4"
7/8"
2-1/2"
J37522MR3
3/8"
1"
3"
J37522ML3
3/8"
1-1/4"
3"
J50022MR3
1/2"
1-1/4"
3"
J50022ML3
1/2"
1-3/4"
4"
Back to
Top
Double sided laminates or Hardwoods
Finishes both top and bottom of material
High feed rates
2
& 3 Flute Compression Up / Down Shear
Used for double sided laminates,
giving a good finish to both top and bottom. Cutting
speed should be reduced for best finish, as chips
are forced back into material.
Recommended
for hardwoods or dense material, utilizing high
feed rates.
Application: Wood
& Wood Composite
Part #
Diameter
Cutting Length
Overall Length
G18722ML3
3/16"
7/8"
2-1/2"
G25022ML3
1/4"
1"
2-1/2"
G37522ML3
3/8"
1-1/8"
3"
G50022ML3
1/2"
1-3/4"
4"
G50032MR3
1/2"
3"
G50032ML3
1/2"
1-3/4"
3-1/2"
G62522ML3
5/8"
